High quality AC220V Digital Temperature Controller PID XMTD Digital Temperature Controller

Ask Lasest Price
Brand Name :	Elexpert/KAMPA
Model Number :	XMTD
Price :	$9.50/Pieces 30-199 Pieces

Add to Cart

Product Details
Company Profile

High quality AC220V Digital Temperature Controller PID XMTD Digital Temperature Controller

High quality AC220V Digital Temperature Controller PID XMTD Digital Temperature Controller Free Shipping

1.Features

Using industrial-grade CPU, strong anti-interference ability; Multiple input signal and output types are available; Multiple alarm types, suitable for the use of different applications; Stable and reliable performance, meet low-cost temperature control requirements.

2.Specification

Input Signal	Thermocouple (××1type) RTD(××2type)voltage (××3type) resistance (××4type)current (××5type)
Adjusting Mode	Two digits adjusting (×0×type) three digits adjusting(×2×type) time proportion adjusting (×3×type) silicon controlled phase-shifting(×6×type)Silicon controlled zero cross(×7×type) silicon controlled three phases zero cross (×8×type) PID adjusting (×9×type)
Outline& Installing Dimension	Outline dimension 160×80mm installing dimension 152×76mm’
Rated Voltageof power Supply	AC220V±10% 50/60Hz
Precision	Display precision 0.1 class, control precision may reach ±1°C
Work Environment	temperature 0~50°C, relative humidity ≤85%
Output Capacity Of Contact	Relay connection point 5A 250VAC, Voltage of no connection point DC12V for SSR use
Proportion Cycle	relay: 30 secs., no connection point: 2 secs.
power Consumption	≤5W
Temperature Range	thermocouple 0~1800°C RTD -200~600°C

High quality AC220V Digital Temperature Controller PID XMTD Digital Temperature Controller
